Features:
Specifications |
Alarm relay contact type | NC |
Current consumption (mA) | 18 – 26 mA |
Detection radius (m) | 18 m |
Dimensions (H x W x D) (mm) | 127 x 69 x 58 mm |
Impact protection | IK04 |
Installation height (m) | 2 – 3 m |
Number of areas | 86 |
Operating temperature (°C) | -30 – 55 °C |
Operating voltage (VDC) | 9 – 15 VDC |
Tamper relay contact type | NC |
Transmission frequency (GHz) | 10.5250 GHz |
Trouble relay contact type | NC |
Wireless transmission frequency | 10.525 GHz |
