Features:
| Specifications |
| Alarm relay contact type | NC |
| Current consumption (mA) | 18 – 26 mA |
| Detection radius (m) | 18 m |
| Dimensions (H x W x D) (mm) | 127 x 69 x 58 mm |
| Impact protection | IK04 |
| Installation height (m) | 2 – 3 m |
| Number of areas | 86 |
| Operating temperature (°C) | -30 – 55 °C |
| Operating voltage (VDC) | 9 – 15 VDC |
| Tamper relay contact type | NC |
| Transmission frequency (GHz) | 10.5250 GHz |
| Trouble relay contact type | NC |
| Wireless transmission frequency | 10.525 GHz |
