1X Bosch IP panel PCB only (CC615PB)
|
CC615PB Features:
-
-
- 16 onboard zones (expandable to 144 wired or wireless)
- Partitionable to 8 areas
- Integrated access control for up to 16 doors
- 8 Wired Devices
- five onboard outputs (expandable to 37)
- IP Reporting via CSV-IP, Connetix, SIA, MyAlarm.
|
|
1X Enclosure (MW350)
|
MW350 Features:
-
-
- Suits Solution 6000, 144, 16i, and 16 Plus series
- Room for five standard modules
- Comes with tamper switch & bracket
- Includes lid screws.
|
|
2x Bosch Wireless PIR Sensors (RFPR-12)
|
RFPR-12 Features:
-
-
- Two models are available, PIR and PIR C, for living spaces containing curtains
- 12 m x 12 m (40 ft x 40 ft) Coverage pattern for RADION PIR
- 12 m x 1.5 m (40 ft x 5 ft) Coverage pattern for RADION PIR C (curtain)
- Flexible Mounting Height
- Pet immunity up to 13 kg (30 lb)
- Operational for up to 5 years with one user replaceable
- CR123A battery
- Supervised for low-battery, cover-tamper, and removal from mounting surface tamper conditions
|
|
1X Wi-Fi-enabled keypad (CP737B)
|
CP737B Features:
-
-
- WIFI Connectivity
- 3.5" Colour screen
- Built-in Smart Card reader allows users to present a token or card at the keypad to arm or disarm the
system
- Large graphical display with LED backlight, with real-time clock and temperature display, and adjustable volume, backlight, and contrast
- Up to 4 lines of 20 characters and icons, with dedicated ON, OFF, and PART keys
- Alphanumeric text prompting/programming with custom installer static display screen
- Terminal block connections.
- Power: +12VDC, 110mA Max (LAN
powered +9VDC - +16VDC)
|
|
1X Wireless Receiver (B810)
|
B810 Features:
-
-
- Connects RADION wireless peripherals such as motion sensors and special detectors, keyfobs, panic buttons, door window
contacts, repeaters, and more to Bosch-supported control panels using the SDI2 Bus connection.
- Dual internal antennas provide spatial and polar RF signal reception for high reliability
- Cover and wall tamper protection
- Multiple device enrollment options, as well as RF diagnostics, ensure efficient and effective installation
- Supports supervision of wireless points (504), keyfobs (1000), and repeaters (8)
- External status LEDs
- Detection and reporting of radio frequency interference.
|
|
1X Bosch Fire Fly type Slimline Siren with Strobe (WP06)
|
WP06 Features:
-
-
- Siren tone selectable for different applications
- Sound volume adjustable: low dB for testing and high dB for regular operation
- Loud: up to 110dB
- Bright: new LED strobe design
- Independent siren and strobe operation
- High-quality UV-treated case
- Weatherproof
- Front and back tampers
- EOLRs built-in, suitable for most major alarm panels
- Dimensions 200 x 110 x 70mm.
|
|
1X Top Hat Piezo (WP08)
|
WP08 Features:
-
-
- Surface Mount
- SPL: 105dB/m
- Current: 110mA
- Voltage: 12VDC.
|
|
1X General Battery (CJ12-7)
|
CJ12-7 Features:
-
-
- CJ series is a general-purpose battery with five years of design life in float service.
- It meets IEC and JIS standards.
- With updated AGM valve-regulated technology and high-purity raw materials,
- the CJ series battery has a reliable standby service life. It suits UPS/EPS, medical equipment, emergency lights, and security systems applications.
- CJ12-7 (12V7Ah).
|
|
1X Bosch Alarm 18V Power Plug (TF008-B)
|
TF008-B Features:
-
-
- 240 VAC primary
- voltage input. 18 VAC
- 1.3 A secondary input
- Includes thermal fuses and a three‑wire flying lead with an earth connection.
|
