System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Embedded processor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
Embedded Linux operating system |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF; SDK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol |
RTSP; RTP; SIP; DNS; SSH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Type |
Capacitive touchscreen |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display |
10" TFT |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Resolution |
1024 × 600 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711a; G.711u; PCM |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
Built-in speaker |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Mode |
2-way Audio |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Enhancement |
Echo suppression |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Bit Rate |
16 kHz; 16 bit |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Mode |
Digital 2-wire |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Information Release |
Receive and view text information released by the management center |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Leave Videos |
Yes (insert an SD card into the indoor monitor) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DND Mode |
Do not disturb period can be set; Do not disturb mode |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Number of Extensions |
Villa: 3 Apartment: 2 Wi-Fi intercom: 1 main monitor, 2 extension monitors |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wi-Fi |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Standard |
IEEE802.11b/802.11g/802.11n |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Frequency Range |
2,412–2,472 MHz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Security Encryption |
WPA/WPA2; WPA-PSK/WPA2-PSK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
Micro SD card (up to 64 GB) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
Metal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SOS |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input |
6 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Bell |
Yes (use any alarm input port) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
One two-wire port and one 10Mbps/100Mbps Ethernet port (one of them can be selected) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color |
Siliver |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
48 VDC 1.25 A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Surface Mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE; FCC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
250 mm × 190 mm × 23.5 mm (9.84" × 7.48" × 0.93") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
–10°C to +55°C (+14°F to 131°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10%–95% RH (non-condensing) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Altitude |
Beneath 3000 m (9842.52 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
Standby ≤ 3 W; working ≤ 7 W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.67 kg (1.47 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
0.85 kg (1.87 lb) |
