- Compatible with any Z-Wave Controller
- Advanced microprocessor control
- Compatible with regular and parametric alarm lines (can be connected to 2 alarm detectors)
- Compatible with binary sensors (can be connected to 2 binary outputs)
- Compatible with DS18B20 temperature sensors (can be connected to four DS18B20 temperature sensors)
Specification:
| Power supply: | 9-30V DC ±10% |
| Inputs: | 2 potential-free inputs 1 digital input 1-wire |
| Outputs: | 2 potential-free outputs |
| Maximum current carrying capacity of outputs: | 150mA |
| Maximum voltage at output contacts: | 36V DC / 24V AC ±5% |
| Measurement range: | -55°C – +126°C |
| Operational temperature: | 0-40°C |
| Supported temperature sensors: | up to 4 DS18B20 sensors |
| In accordance with EU standards: | RoHS 2011/65/EU EMC 2004/108/EC R&TTE 1999/5/EC |
| Radio protocol: | Z-Wave |
| Radio signal power: | up to 1mW |
| Radio frequency: | 868.4 MHz EU; 908.4 MHz US; 921.4 MHz ANZ; 869.0 MHz RU; 865.2 MHz IN; |
| Radio transmit power: | up to -1 dBm (EIRP) |
| Range: | up to 50 m outdoors up to 30 m indoors (depending on building materials) |
| Dimensions: (L x W x H)): | 27.3 x 14.5 x 12 mm |
