Home Center 3 Lite is a smaller version of the most advanced smart home management unit in the world. The device has been designed based on the solutions used in the Home Center 3 platform. This central unit can be connected with other Z-Wave devices which you can use while controlling electronics and household appliances, lighting, blinds, HVAC, alarm or watering system - with just a single button, gesture or word. Home Center 3 Lite is recommended for flats and smaller smart home installations.
Features:
Provides a reliable foundation for FIBARO System,
Capable of controlling all FIBARO and other compatible devices using the following radio standards:
Nice FLOR, OPERA i PLN2+,
Elero PLN2
Z-Wave (700 series),
Wi-Fi – 2.4 GHz (802.11 b/g/n).
Allows to add up to:
40 Nice devices (recommended),
40 Z-Wave devices (recommended),
1 IP camera,
20 scenes,
10 Quick Apps,
5 plugins.
No Internet cable required, works on Wi-Fi,
Modern interface designed for ease of use,
Enhanced and convenient scene editor,
Support for more advanced apps and drivers,
May be used with all devices certified with the Z-Wave Plus certificate and should be compatible with such devices produced by other manufacturers.
Specifications:
General information
Model
HC3L-001
Power supply
5V DC , max. 1A (adapter included)
Operating temperature
0-40°C
Operating humidity
max. 75% relative humidity (non-condensing)
Power connector
USB Micro B
Dimensions
178x110x31 mm
Radio Communication
Protocol
Radio frequency band
Max. transmitting power
Z-Wave (700 series)
868.0-868.6 MHz 869.7-870.0MHz
+9dBm
Wi-Fi (802.11 b/g/n)
2400-2483MHz
+20dBm
Status indicator
Pulsing blue – start-up
Red – Wi-Fi in Access Point mode (ready to configure)
Pulsing copper – disconnected from the Internet
Green – connected to the Internet
Pulsing red – start-up to Recovery mode
Buttons
R – Reboot
Restart: hold R button for 5s
D – Recovery
Put the gateway in Recovery mode: hold D button during start-up
Switch between Dynamic and Static IP: hold D button for 10s, then click when diode is blinking:
yellow blinking: IP will switch to Dynamic
green blinking: IP will switch to Static
Reset network settings: hold D button for 20s, then click when diode is blinking red
