Specifications:
Model | DS-3E0524TF |
Network parameters | |
Port number | 12 Gigabit Ethernet electrical ports and 12 Gigabit SFP fiber optical port |
Port type | Electrical ports: RJ45, Full/half duplex, MDI/MDI-X self-adptive Fiber optical port: SFP packaging |
Standard | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x |
Processing type | Store-and-forward switching |
Priority queue | 8 |
Mac address table | 16 K |
Switching bandwidth | 48 Gbps |
Packet forwarding rate | 35.7 Mpps |
Internal cache | 12 Mbit |
Mechanical structure | |
Shell | Metal material |
Weight | 2.5 kg |
Dimensions (L × H × D) | 440 × 44.5 × 186.5 mm (17.3 × 1.8 × 7.3 inch) |
Environment | |
Operating temperature | -5 ˚C to +50 ˚C (+23 ˚F to +122 ˚F) |
Storage temperature | -40 ˚C to +85 ˚C (-40 ˚F to +185 ˚F) |
humidity | 5% to 95% (no condensation) |
Power supply | |
Power supply | 220 VAC |
Consumption | ≤ 30 W |
Safety and reliability | |
ElectroSTatic Discharge (ESD) |
Contact discharge:±7 KV Air discharge:±9 KV |
Surge immunity(Surge) |
Power port:line-ground ±2 KV,line-line 1 KV Network port:line-ground ±2 KV |
Electrical fast transient(EFT) |
Power port:±2 KV Network port:±1 KV |
