System parameters | |
Operation system | Linux |
ROM | 32 MB |
RAM | 128 MB |
Processor | Embeded high performance processor |
Display parameters | |
Screen size | 7-inch |
Operation method | Capacitive touch screen |
Type | Colorful TFT |
Resolution | 1024 × 600 |
Video parameters | |
Lens | / |
Resolution | / |
FOV | / |
Wide dynamic range (WDR) | / |
Focal length | / |
Audio parameters | |
Audio input | 1 built-in omnidirectional microphone |
Audio compression standard | G.711U, G.711A |
Audio output | 1 built-in loudspeaker |
Audio compression bitrate | 64 Kbps |
Audio quality | Noise suppression and echo cancellation |
Volume adjustment | Adjustable |
Capacity | |
Message capacity | 200 captured pictures (with TF card); 200 alarm records 2 MB RAM (without TF card) reserved for events |
Notice capacity | 200 |
Linked network camera capacity | 16 |
Linked indoor extensions capacity |
16 |
Linked doorphone capacity | 2 analog doorphones, 15 network doorphones |
Network parameters | |
Network protocol | TCP/IP, SIP, RTSP |
Wi-Fi | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
Bluetooth | / |
3G/4G | / |
Zigbee | / |
Device interfaces | |
Alarm input | 2 |
Network interface | 1 RJ-45 10/100 Mbps self-adaptive |
TAMPER | / |
RS-485 | 1 RS-485 (Half duplex) |
USB | / |
TF card | Support TF card, up to 128 G |
Alarm output | 2 |
Lock control | 2 relays, Max. 30 VDC 0.3 A |
Four-Wire interface | 2 |
General | |
Button | / |
Installation | Surface mounting |
Indicator | / |
Weight | Net weight: 340 g (0.75 lb) Gross weight: 709 g (1.56 lb) |
Protective level | / |
Working temperature | -10 °C to 55 °C (14 °F to 122 °F) |
Working humidity | 10% to 90% (no-condensing) |
Dimension (W × H × D) | 200 mm × 140 mm × 23.6 mm (7.9" × 5.5" × 0.9") |
Battery | / |
Power supply | 12 VDC, IEEE802.3af, standard PoE |
Application environment | Indoor |
Power consumption | ≤ 5 W |
Language | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian |
