System parameters | |
Operation system | Linux |
ROM | 32 MB |
RAM | 128 MB |
Processor | Embeded high performance processor |
Display parameters | |
Screen size | 7-inch |
Operation method | Capacitive touch screen |
Type | Colorful TFT |
Resolution | 1024 × 600 |
Video parameters | |
Lens | / |
Resolution | / |
FOV | / |
Wide dynamic range (WDR) | / |
Video compression standard | / |
Focal length | / |
Audio parameters | |
Audio input | 1 built-in omnidirectional microphone |
Audio compression standard | G.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1 |
Audio output | 1 built-in loudspeaker |
Audio compression bitrate | 64 Kbps |
Audio quality | Noise suppression and echo cancellation |
Volume adjustment | Adjustable |
Capacity | |
Message capacity | TF card inserted: 200 captured pictures, 200 alarm records Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records |
Notice capacity | 200 |
Linked indoor extensions capacity |
16 |
Linked doorphone capacity | 17 |
Network parameters | |
Network protocol | TCP/IP, SIP, RTSP |
Wi-Fi | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
Bluetooth | / |
3G/4G | / |
Zigbee | / |
Device interfaces | |
Alarm input | 8 |
Network interface | 1 RJ-45 10/100 Mbps self-adaptive |
TAMPER | / |
RS-485 | 1 RS-485 (Half duplex) |
USB | / |
TF card | Support TF card, up to 128 G |
Alarm output | 2 |
Lock control | 2 relays, Max. 30 VDC 0.3 A |
General | |
Button | / |
Installation | Wall mounting, table mounting |
Indicator | / |
Weight | Net weight: 355 g (0.8 lb) Gross weight: 683 g (1.5 lb) |
Protective level | / |
Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
Working humidity | 10% to 90% (no-condensing) |
Dimension (W × H × D) | 175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83") |
Battery | / |
Application environment | Indoor |
Power consumption | ≤ 5 W |
Language | English, Arabic, French, Russian, Spanish, Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Chinese Traditional |
Power supply | 12 VDC, 1 A,IEEE802.3af, Standard PoE |
