Network | |
Wired network | 1, 10/100/1000 Mbps self-adaptive |
Interface | |
Network interface | 1 |
Lock control | 4 |
Exit button | 4 |
Door contact input | 4 |
Alarm input | 8 |
Alarm output | 4 |
TAMPER | 1 |
RS-485 | 7, 2 for card reader, 5 for access modules (4 for communication, each interface can connect up to 16 access modules; 1 for redundancy) |
Wiegand | 4, standard 26/34 input, supports custom Wiegand settings |
USB | 1, USB 2.0 |
Fire interface | 1 |
Capacity | |
User capacity | 100,000 |
Fingerprint capacity | 10,000 |
Card capacity | 200,000 |
Event capacity | 600,000 |
Linked door capacity | Self: 4 doors Extended: up to 128 doors (connected with 62 access modules) |
Linked card reader capaciry | 8 RS-485 card readers (OSDP protocol) and 4 Wiegand card readers |
Authentication | |
Fingerprint recognition duration | < 1 s |
General | |
Indicator | 12 indicators, 1 for indicating power status, 1 for running status, 1 for wired network status, 5 for RS-485 status, and 4 for door status |
Battery | Charge and discharge |
Power supply | 12 ± 15% VDC |
Power consumption | ≤ 102 W |
Working temperature | -10 °C to 55 °C (14 °F to 131 ° F) |
Working humidity | 0% to 90% (No condensing) |
Installation | Installation with guide rail |
Language | English, Thai, Traditional Chinese, Indonesian, Vietnamese, Arabic, Spanish (Europe), Spanish (South America), Italian, French, Dutch, Russian, Ukrainian, Portuguese (Europe), Portuguese (Brazil), Serbian, Croatian, Bulgarian, German, Greek, Romanian |
Function | |
Configuration via Web browser | Support |
Multi-factor authentication | Support |
First person in | Support |
Anti-passback | Support 32 routes (64 card readers each) |
Multi-door interlocking | Support 32 groups (32 doors each) |
