System | |
Operating system | MCU |
Interface | |
Lock control | 2 |
Exit button | 2 |
Door contact input | 2 |
Alarm input | 4 |
Alarm output | 2 |
TAMPER | 1 |
RS-485 | 4, 2 for card reader, 2 for access controller |
Wiegand | 2, standard 26/34 input, supports custom Wiegand settings |
Capacity | |
Linked door capacity | 2 doors |
Linked card reader capaciry | 4 RS-485 card readers (OSDP protocol) and 2 Wiegand card readers |
General | |
Indicator | 6 indicators, 1 for indicating power status, 1 for running status, 2 for communication status, and 2 for door status |
Battery | Charge and discharge |
Power supply | 12 ± 15% VDC |
Power consumption | ≤ 50 W |
Working temperature | -10 °C to 55 °C (14 °F to 131 ° F) |
Working humidity | 0% to 90% (No condensing) |
Installation | Installation with guide rail |
Function | |
Configuration via Web browser | Support via access controller |
Multi-factor authentication | Support via access controller |
First person in | Support via access controller |
Multi-door interlocking | Support via access controller: supports 32 groups (32 doors each) |
