System parameters | ||
Operation system | Embedded Linux operation system | |
ROM | 32 M | |
RAM | 256 M | |
Processor | Embedded MCU Processor | |
Display parameters | ||
Screen size | / | |
Operation method | / | |
Type | / | |
Resolution | / | |
Video parameters | ||
Lens | 1 | |
Resolution | Main stream : 1920 × 1080 Sub stream : 640 × 480 |
|
FOV | Horizontal:95° Vertical:54° |
|
Wide dynamic range (WDR) | Support | |
Supplement light | IR supplement | |
Video compression standard | H.264 | |
Audio parameters | ||
Audio input | Built-in omnidirectional microphone | |
Audio compression standard | G.711 U,G.711 A | |
Audio output | Built-in loudspeaker (More than 80 dB within 30 cm) | |
Audio compression bitrate | 64 Kbps | |
Audio quality | Noise suppression and echo cancellation | |
Volume adjustment | Adjustable | |
Capacity | ||
Face capacity | / | |
Card capacity | / | |
Linked indoor station capacity | 1 | |
Sub door station capacity | 16 | |
Network parameters | ||
Network protocol | TCP/IP, RSTP, SIP | |
Wi-Fi | / | |
Bluetooth | / | |
3G/4G | / | |
Device interfaces | ||
Alarm input | 1 | |
Network interface | 1 RJ-45, 10/100 Mbps self-adaptive | |
Lock control | 1 relay, Max. to 30 VDC, 2 A) | |
General | ||
Button | 1 | |
Installation | Surface mounting | |
Weight | Net Weight: 0.795 kg Gross Weight: 0.992 kg |
|
Protective level | IP65, IK09 | |
Working temperature | -30 °C to 50 °C(-22 °F to 122 °F) | |
Working humidity | 10% to 90% (no-condensing) | |
Dimension (W × H × D) | 161.85 mm × 74.13 mm × 53.2 mm(6.37" × 2.92" × 2.09") | |
Battery | / | |
Power supply | 12 VDC, IEEE802.3af, standard PoE | |
Application environment | Outdoor and Indoor | |
Power consumption | < 10 W | |
Language | English,French,Portuguese,Spanish,Russian,German,Italian,Polish,Arabic,Turkish,Vietn amese,Hungarian,Dutch,Romanian,Czech,Bulgarian,Ukrainian,Croatian,Serbian,Greek, Slovakia,BrazilianPortuguese |
