Hikvision Wired internal 18m PIR detector DS-PDP18-EG2

Overview:

DS-PDP18-EG2 series of passive infrared detectors are equipped with dual-element infrared sensors and 3D Fresnel lens technology. Its range can reach 18 meters. When moving objects are detected in the area, the detector will output the alarm signal that has been by the circuit, analyzed, and calculated by the microprocessor algorithm. It is suitable for various indoor scenes.

Wired internal 18m PIR detector, features:

• Modern design - Delivers a small and sleek detection solution; providing a modern yet unobtrusive finish to complement any room.
• Detection range - Up to 18m volumetric detection coverage, the Ellipse is the ideal solution for any small to large indoor rooms and spaces.
• Digital temperature compensation – Digitally adjusts its sensitivity to maintain its specified range when the background temperature is close to body temperature.
• Automatic sensitivity - self-adapts to changing environmental conditions to maintain stability and intruder catch performance.
• 3D optics - Improves the detection of moving targets; ensuring more precise signals can be received from the PIR by enabling the perfect focusing of the infra-red signal onto the pyro-electric sensor.
• Creep-zone protection - covers the blind spot area directly below it, where an intruder may have otherwise avoided detection.
• Selectable EOL resistors - incorporates selectable alarm resistor values of 1K, 2K2, 4K7, 5K6, and 8K2, as well as tamper resistance values of 1K, 2K2, 4K7, and 5K6; catering for most control panels on the market.
• Wall and ceiling mount options - can be fitted at a mounting height of 1.8m to 2.4m. There is also a ceiling mount option available if required.
• Anti-insect interference - Protects the detector from possible insect infestation, as well as shields air movement in front of its pyro-electric sensor and protects against adverse reflections from inside the detector housing.
• Wide voltage - 9 to 16 V wide voltage adaptation with polarity reverse connection protection
• IFT technology - automatically adjusts the upper and lower alarm trip thresholds when exposed to electromagnetic or electrical interference and shifts the thresholds before the detector goes into a false alarm.
