● HD TVI video quality
● Plug & Play
● Water and dust resistant (IP65)
● One-press to call
Door station | |
Supplement light | IR light, up to 3 m |
Resolution | Stream resolution:1280 * 720@60fps |
FOV | Horizontal: 117°, Vertical: 70°, Diagonal: 141° |
Door station | |
Audio input | 1 built-in omnidirectional microphone |
Audio output | 1 built-in loudspeaker |
Door station | |
Linked indoor station capacity | 3 |
Sub door station capacity | 1 |
Card capacity | / |
Door station | |
Lock control | 1 relay, max 30 V 1 A |
Power supply input | 12 VDC |
Debugging port | 1 |
Four-Wire interface | 1 |
Door station | |
Button | 1 physical button(s) |
Indicator | / |
Power supply | 12 VDC |
Power consumption | ≤ 4 W |
Working temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
Working humidity | 10% to 90% (no-condensing) |
Dimension (W × H × D) | 55 mm × 145 mm × 24 mm (2.17" × 5.71" × 0.94") |
Application environment | Outdoor |
Installation | Surface mounting |
Protective level | IP65, IK08 |
Weight | Without package: 200 g (0.44 lb) |
Material | Aluminum alloy and Plastic |
