Specifications |
|
| Operation system | Linux |
| Memory | 128 MB |
| Flash | 32 MB |
| Display screen | 7-inch colorful TFT screen |
| Display resolution | 1024 × 600 |
| Operation method | Capacitive touch screen |
| Audio input | 1 built-in omnidirectional microphone |
| Audio output | 1 built-in loudspeaker |
| Audio quality | Noise suppression and echo cancellation |
| Audio compression standard | G.711 U |
| Audio compression Rate | 64 Kbps |
| Wired network | 1 RJ-45, 10/100 Mbps self-adaptive |
| Wireless network | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Protocol | TCP/IP, SIP, RTSP |
| RS-485 | 1 RS-485 (Half duplex) |
| Alarm input | 8-ch alarm inputs |
| Relay output | 2 |
| TF card | Support TF card, up to 128 G |
| Power consumption | ≤ 5 W |
| Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working humidity | 10% to 90% |
| Dimension (L x W x H) | 175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83") |
