SONY Starvis sensor, Human and vehicle tracking, Extra photos/frames per second (FPS), Improvements to Wide Dynamic Range (WDR) to handle tricky lighting. Locking mechanism on housing. Supports SD card—new tech Infrared LEDs.
SONY Starvis sensor, Human and vehicle tracking, Extra photos/frames per second (FPS), Improvements to Wide Dynamic Range (WDR) to handle tricky lighting. Locking mechanism on housing. Supports SD card—new tech Infrared LEDs.
Specifications |
Camera Type | Dome |
Image Sensor | 1/2.8” 8MP Progressive CMOS |
Maximum Video Resolution (Megapixels) | 8 |
Maximum Video Resolution | 3840 x 2160 |
Lens | 3.6 mm (H.FOV: 88°) |
Lens Type | Fixed |
Maximum Night IR Distance (M) | 30 |
Image clarity | 4 |
Connectors | RJ-45 |
Video Compression | H.265, H.264 |
ONVIF (depends on firmware version) | ONVIF( Profile S/G/T) |
Operating Environment | -30 to +55°C/less than ≤ 95% RH |
Dimensions | 100×100 mm |
Weight (Net) | 0.44 |
Accessories | IV2422X, IV2433X, IV2444X, IV2455X |
Power Supply | Power over Ethernet IEEE 802.3af, DC12V |
Power Consumption | <7W |
Connectors (web) | RJ-45, DC Power Input |
Outdoor Use | Yes |
IP Rating | IP66 |
Vandal Resistant | Yes |
Frame Rate at Resolution | 20 |
Day/Night Mode | Auto |
Image Enhancement | Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue |
Edge Recording slot microSD/SDHC Card | Yes |
Video Compression | H.265, H.264 (3 streams) |
Audio Streaming | Yes (microphone included) |
Protocols | TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SNMP, P2P (QR code) |
Intelligent Video | IVS such as Perimeter Intrusion Detection, Human and Vehicle Detection, Face Detection, Motion Detection. |
Software | Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app |
Power Over Ethernet | Yes |
Ethernet | Ethernet (10/100 Base-T) |
UPNP | Yes |
In The Box | Free Software available from FAQ, Printed quick user guide, installation template, mounting screws and plugs |
Warranty | 3 Year Warranty |
