| Maximum Channels |
8 |
| Max Video Resolution (MP) |
12 |
| Examples of Channels at resolution FPS |
128 Mbps |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
| Video Output Resolution |
4K, HD-1080p, HD-720p, 1.3 MP, D1, VGA |
| Display Layout |
1 / 4 / 6 / 8 / 9 |
| Search Method |
Continuous, Scheduling, Event Triggered ( PIR, IVS, Motion, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Pedestrian Detection, Face Detection, Cross Counting) |
| Total Storage (TB) |
32 |
| HDD Bays Size |
Bays x 2, up to 16TB HDD per bay |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app |
| Protocols |
TCP, HTTP, HTTPS, DHCP, DDNS, NTP, SMTP, PPPOE, RTSP, UPnP, ONVIF, P2P, QR Code |
| Language |
English, French, Dutch, German, Italian, Polish, Portuguese, Spanish, Thai, Turkish, Hungarian, Simplified Chinese, etc |
| Audio Streaming |
Out |
| PoE Built in Switch |
8 up to 802.3at(30w) |
| Power Supply |
DC48V/2A 8W (excl. cameras and HDD) |
| Connectors |
HDD: 3.5″ SATA HDD Slot x 1, USB2 Female x 2, USB3 Female x 1, Gigabit Ethernet: RJ-45 Port x 1 and 8 x PoE+ ports, HDMI and VGA, Alarm ports 8 in and 1 out, Audio out, Power Jack input, On off switch |
| Operating Environment |
5ºC to 45ºC (41ºF-113ºF) Humidity: 20%-80% RH |
| In The Box |
Printed quick installation guide, Mouse, Remote control, HDD screws, Power supply. |
| Model |
NR3082X |
| Weight |
1000 |
| Warranty |
24 months parts & labour warranty |
| Dimensions |
300x227x53 mm |
