Basic | |
Dimensions(W×D×H) | 119 mm × 119 mm × 200 mm (4.7 in. × 5 in. × 7.9 in. antennas not included) |
Weight | 0.66 kg (packages not included) |
Wi-Fi Standards | Wi-Fi 6 (802.11ax) |
MIMO | 2.4 GHz, 4×4, MU-MIMO 5 GHz, 4×4, MU-MIMO |
Max. Wi-Fi Speed | 2.4 GHz: 800Mbps 5 GHz: 2402Mbps |
Channel Width | 2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80MHz |
Antennas | 4 dual-band |
Antennas Type | Internal Omnidirectional |
Antenna Gain | 2.4 GHz: 4 dBi 5 GHz: 4 dBi |
WAN Port | 1×10/100/1000 Base-T |
LAN Ports | 3×10/100/1000 Base-T |
Recommended Users | 60 |
Max. Users | 192 |
Power Supply | DC 12V/2A |
Power Consumption | ≤ 30 W |
Operation Frequency Bands | 802.11b/g/n/ax: 2.400 GHz to 2.483 GHz 802.11a/n/ac: 5.150 GHz to 5.350 GHz 802.11a/n/ac/ax: 5.470 GHz to 5.725 GHz , 5.725 GHz to 5.850 GHz country-specific restrictions apply |
DFS | Support |
Transmit Power | European Union & United Kingdom 2400-2483.5 MHz, EIRP≤ 20 dBm 5150-5350 MHz, EIRP≤ 23 dBm |
5470-5725 MHz, EIRP≤ 30 dBm United States: 2400-2483.5 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5150-5250 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5250-5350 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5470-5725 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5725-5850 MHz, max output power≤30dBm & EIRP ≤ 36 dBm Myanmar : 2400-2483.5 MHz, EIRP ≤ 23 dBm 5725-5825 MHz, EIRP ≤ 30 dBm Thailand: 2400-2483.5 MHz, EIRP ≤ 20 dBm 5150-5350 MHz, EIRP ≤ 23 dBm 5470-5725 MHz, EIRP ≤ 30 dBm 5725-5825 MHz, EIRP ≤ 30 dBm Indonesia: 2400-2483.5 MHz, EIRP ≤ 27 dBm 5150-5350 MHz, EIRP ≤ 23 dBm 5725-5825 MHz, EIRP ≤ 23 dBm Egypt: 2400-2483.5 MHz, EIRP ≤ 20 dBm 5150-5350 MHz, EIRP ≤ 23 dBm |
Receive Sensitivity | 2.4 GHz: 802.11b: -96 dBm(1 Mbps) 802.11g: -91 dBm(6 Mbps), -85 dBm(54 Mbps) 802.11n: -90dBm(MCS0), -85 dBm(MCS7) 5 GHz: 802.11n: -90 dBm(MCS0), -70 dBm(MCS7) 802.11a: -88 dBm(6 Mbps), -60 dBm(54 Mbps) 802.11ac: -82dBm(MCS0), -57dBm(MCS7), -52dBm(MCS9) |
Operating Temperature | -10 °C to +40 °C (14 °F to 104 °F) |
Operating Humidity | 5% to 95% Noncondensing |
Certifications | CE, SIRIM, RCM RoHS |
Wireless | |
OFDMA | Support |
MU-MIMO | Support |
BSS Coloring | Support |
Maximum Number of SSIDs | 6 |
SSID Hiding | Support |
Band Steering | Support |
Guest Wi-Fi | Support |
WPA/WPA2 | Support |
WPA3 | - |
Roaming | Layer 3 Roaming |
Blocklist | Support |
Reyee Mesh | Support |
Mesh Pairing by Hardware | Support |
Mesh Pairing by Mesh Button | Support |
Mesh Pairing by Eweb | Support |
Recommended Hop Count | ≤2 |
Wi-Fi Optimization | Support |
QoS (WMM) | Support |
WPS | - |
Transmission Power Adjustment | Support |
Hardware | |
CPU | MT7622B+MT7911AN+MT7915AN |
Flash | 16 MB |
RAM/SDRAM | 256 MB |
Color | Black |
System LED Indicator | Support |
Reyee Mesh LED Indicator | Support |
Reyee Mesh Button | Support |
Power Button | - |
Reset Button | Support |
DC Connector Dimensions | Outer Diameter: 5.5 mm Inner Diameter: 2.0 mm Length: 11.5 mm (Outer Diameter: 0.22 in. Inner Diameter: 0.07 in. Length: 0.39 in. ) |
WAN | |
Static IP | Support |
DHCP | Support |
PPPoE | Support |
Learning PPPoE Account & Password | Support |
VLAN Tagging | Support |
LAN | |
DHCP Server | Support |
Client List | Support |
Static IP Assignment | Support |
Port-Based Flow Control | Support |
Features | |
TR069 | Support |
Preset | Support |
IPv6 | Support |
DDNS | Support |
IPTV | Support |
Alarm | Support |
Diagnosis | Support |
UPnP | Support |
ARP Binding | Support |
Port Mapping | Support |
DMZ Host | Support |
Rate Limitation of Terminals | Support |
Hardware Acceleration | Support |
MAC Address Cloning | Support |
Cloud Management | Support |
Repeater Mode | Support |
WISP Mode | Support |
AP Mode | Support |
Security | |
PPTP VPN Server | Support |
PPTP VPN Client | Support |
L2TP VPN Client | - |
Parental Control | Time Schedule |
Protect TCP Flood Attacks | Support |
Protect ICMP Attacks | - |
Protect UDP Flood Attacks | - |
System | |
Default Access/Password | 192.168.110.1 No Password Required by Default |
URL Access | Support |
Local Upgrade | Support |
Online Upgrade | Support |
APP Upgrade | Support |
Syslog | Support |
Backup | Support |
Factory Reset | Support |
Language | Chinese English Vietnamese Indonesian Thai Arabic Traditional Chinese Spanish Russian |
