Shelly Wave i4 AU SH-SHELLYWAVE-I4
- SH-SHELLYWAVE-I4
- BRANDS, SECURITY & AUTOMATION
Shelly Wave i4 AU SH-SHELLYWAVE-I4
Features:
- Wave i4 is an input reader device (it does not contain relays)
- Manually control other Z-Wave devices (e.g. with a multi-button switch)
- Multi-click – activation of up to 12 actions
- Extremely low power consumption: < 0.2 W
- Z-Wave frequency band: 919.8 MHz
- Latest technology: Z-Wave 800 Series
- Automatic set-up with SmartStart
- Security 2 Authenticated for the highest level of security
- Over-the-air firmware updates
- Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices
Specifications:
|
Power supply AC |
110 - 240 V AC, 50/60 Hz |
|
Power supply DC |
No |
|
Power consumption |
< 0.2 W |
|
Overcurrent protection |
No |
|
Power measurement |
No |
|
Number of inputs |
4 |
|
Distance |
Up to 40 m indoors (131 ft.) (depends on local condition) |
|
Z-Wave® repeater: |
Yes |
|
CPU |
Z-Wave® S800 |
|
Z-Wave® frequency band |
919.8 MHz |
|
Maximum radio frequency power transmitted in frequency band(s) |
< 25 mW |
|
Size (H x W x D) |
37x42x16 ± 0.5 mm / 1.46x1.65x0.63 ± 0.02 in |
|
Weight |
17 g / 0.6 oz |
|
Mounting |
In-wall box |
|
Screw terminals max. torque |
0.4 Nm / 3.5 lbin |
|
Conductor cross section |
0.5 to 1.5 mm² / 20 to 16 AWG |
|
Conductor stripped length |
5 to 6 mm / 0.20 to 0.24 in |
|
Shell material |
Plastic |
|
Color |
Orange |
|
Ambient temperature |
-20°C to 40°C / -5°F to 105°F |
|
Humidity |
30 % to 70 % RH |
