Uniview 2MP ANPR Bullet Camera HC121@TS8C-Z

free-shipping Chat with us now to check the stock. Canberra: Out of Stock | Sydney: Low Stock | Brisbane: Out of Stock | Melbourne: Out of Stock | Perth: Out of Stock
Uniview 2MP ANPR Bullet Camera
Login to See Better Price
* FIND A CHEAPER PRICE WE WILL BEAT IT BY 1% TO 5%

Uniview 2MP ANPR Bullet Camera



uniview



Features:



  • Starlight optical sensor and integrated illuminator for vehicle capture and recognition in low-light environments.
  • 4 LED illumination beads provide up to 50m illumination.
  • 2MP industrial-grade sensor delivers 1920 x 1080 images.
  • Motorized zoom lens enables flexible focal length adjustment and easy installation.
  • Automatic gain control, white balance, and WDR for various light conditions.
  • Built-in vehicle&license plate recognition algorithm can recognize standard license plates of multiple countries.
  • capturing vehicle head only.
  • allowlist and blocklist configuration.
  • vehicle access control when connected to a barrier.
  • Micro SD cards of up to 128GB.
  • Automatic Network Replenishment (ANR), the camera can automatically store video to its SD card in case of network disconnection.
  • audio acquisition and intercom.
  • Supports DC 12V, and PoE (802.3at) power supplies.
  • Cast aluminum body offers excellent heat dissipation.
  • 3-axis mounting bracket for various installation scenarios.
  • Junction box for cabling.
  • IP67, IK10.
  • Up to 1080P@60fps image collection format.
  • 1 image stream, 3 video streams.
  • Up to 1080P@60fps live video streams.
  • Advanced H.265 encoding technology improves compression efficiency.
  • Custom OSD allows various vehicle information to be overlaid on the video image.



Specification:



Camera Description
Sensor 1/2.8” 2MP CMOS
Focal length 4.7 to 47mm, motorized zoom
Shutter Auto/Manual, range: 1/25 to 1/100000 s
Minimum illumination 0.001lux (F1.6)
Image Description
Image collection format 1080P@25 (default), 1080P@30, 1080P@50, 1080P@60
Resolution Main stream: 1080P (default), 720P, D1
Sub stream: 720P (default), D1, 2CIF, CIF
Third stream: D1 (default), 2CIF, CIF
Frame rate 60, 50, 30, 25 (default), 22, 20, 18, 16, 15, 12.5, 10, 8, 6, 5, 4, 3, 2, 1
Video compression H.264 (default), H.265
ROI Supports up to 8 regions
Video OSD Supports 8 overlay areas and allows contents including date, time, date&time, zoom ratio, custom contents
Image OSD Supports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location
Smart Description
Application scenario Vehicle speed ≤30km/h
Supports simultaneous application to entry/exit scenes
Vehicle detection mode Video (default) or inductive loop
Capture vehicle head only Support
License plate number recognition Supports recognition of license plates with numbers and letters by default
List configuration Supports allowlist and blocklist configuration, each list allows 20,000 items
Supports import, export, add, and delete operations
Barrier opening policy Open barrier only for the recognized vehicles
Open barrier for all vehicles
Open barrier only for vehicles on the allowlist
Open barrier for vehicles not on the blocklist
Configurable Boolean output ID
Storage Description
Edge storage Supports ANR with a Micro SD card, up to 128GB
Structure Description
Illumination Built-in integrated illumination module, including 4 white light LEDs, 50m illumination distance, automatic on/off control
Sunshield Long sunshield
Bracket 3-axis mounting bracket
Junction box The camera comes with a junction box for storing tail cable
Interface Description
Network interface 1 × 10M/100M RJ45
Serial port 1 × RS485
Boolean output 1 relay output, withstand voltage: AC 125V/0.3A, DC 30V/1A
Boolean input 2 inputs, supports level/Boolean, with max level up to DC 5V
Audio interface 1 × audio input, 1 × audio output
Storage interface 1 × Micro SD card slot
General Description
Power supply DC12V + 25% - 10%
Max. power consumption: 20W
Supports PoE (802.3at, class 4)
Dimensions (L×W×H) 386mm x 126mm x 130mm
Weight 2kg
Operating environment -40℃ to 60℃, ≤90% RH
Ingress protection IP67, IK10
